steering cylinder
Function:
Steering system for chassis tires of aerial work platforms
Specifications:
Cylinder diameter ranging from 63mm to 200mm
Rod diameter ranging from 36mm to 140mm
Stroke ≤1000mm
Stress
30MPa (maximum working pressure)
Leveling cylinder
Function:
Adjust the angle of the aerial work platform
Specifications:
Cylinder diameter ranging from 85mm to 180mm
Rod diameter: 50mm~100mm
Stroke ≤ 300mm
Stress
30MPa (maximum working pressure)
Outrigger cylinder
Function:
When the aerial work platform is in operation, it supports the weight of the entire equipment
Specifications:
Cylinder diameter ranging from 45mm to 200mm
Rod diameter ranging from 30mm to 180mm
Stroke ≤ 2000mm
Stress
30MPa (maximum working pressure)
Telescopic hydraulic cylinder
Function:
Realize the linear telescopic motion of the boom
Specifications:
Cylinder diameter ranging from 45mm to 200mm
Rod diameter ranging from 32mm to 180mm
Stroke ≤ 15000mm
Stress
30MPa (maximum working pressure)
luffing cylinder
Function:
The main driving force for aerial work platforms is to achieve the up-and-down pitching movement of the boom
Specifications:
Cylinder diameter ranging from 50mm to 350mm
Rod diameter: 30mm~300mm
Stroke ≤ 3000 mm
Stress
30MPa (maximum working pressure)
swinging cylinder
Function:
Implement platform and crank arm swinging
Specifications:
Torque: 500~5000N.m
Swing angle 0~360°
Stress
21MPa (standard working pressure)
electric cylinder
Function:
Implement the stretching and shrinking function
Specifications:
Thrust: 1-1000KN
Stroke: 0-2000mm
Voltage:
24V,48V,220V,380V
